GEPRC Mark5 Pro GEP-MK5 5″ Freestyle Frame Kit – Pro Version

6,699.00

 Overview:

  • The GEPRC MARK5 Pro Frame Kit is explicitly developed for freestyle with a squashed X-arm design.

Availability: Only 1 left in stock

1 user is viewing this product
SKU: SKU3292130 Categories: ,
Spread the love


GEPRC Mark5 PRO GEP-MK5 5″ Freestyle Frame Kit – Pro Version Specifications and Features:



The GEPRC MARK5 Pro Frame Kit is explicitly developed for freestyle with a squashed X-arm design. The unique shock-absorbing structure design, fewer vibrations, and resonance provide a stable operating environment for the electronic system. Aluminum alloy side plates not only look stunning but also reduce weight and add more endurance.



VIDEO: GepRC Mark5 Build EP1: Frame Assembly


Features

  • Two different 3D printed parts bases, which can be installed with GoPro, Naked GoPro8, Insta 360 GO2, and Caddx Peanut cameras.
  • The installation hole of VTX is compatible with DJI Air Unit and VISTA, while maintaining the 30.5*30.5 analog VTX installation hole.
  • Specially designed independent capacitor and buzzer compartment for better performance and shaking reduction.
  • Aluminum alloy side plates not only look stunning but reduce weight and add more endurance.
  • Compatible motor hole design supports the installation of 16x16mm and 19x19mm motors.
  • Supports the installation of 19-20mm width lens, you can directly install DJI original lens.
  • Unique shock-absorbing structure design, fewer vibrations, and resonance.
  • MARK5 is the most ideal for freestyle flying and bando-bashing resistance.
  • Developed specifically for freestyle with a squashed X-arm design.
  • Squashed-X Configuration
  • Black PRO Version





STRONG POWER SYSTEM

Strong power system, 16mm x 16mm / 19mm x 19mm motor holes will allow you to install larger 21-22-23-25 series motors, with 5-inch propellers, with strong power output.

30.5 X 30.5 FLIGHT CONTROLLER SUPPORT

MARK5 frame supports the mainstream 30.5mm x 30.5mm Flight Controller. Pre-set two sets of installation holes,  30.5mm x 30.5mm and 20mm x 20mm Fixing holes respectively. The subsidiary printing parts can also be directly installed with DJI Air Unit.

3D MOUNTS

The MARK5 designed two different 3D printed mounts which can be installed with GoPro /Naked GoPro8/Insta 360 GO2 and Caddx Peanut cameras to record every moment of Freestyle.

COMPATIBILITY

The frame is compatible with DJI AIR UNIT, CADDX VISTA, and Analog VTX.

Specifications

  • VTX Mounting Holes: 30.5mm x 30.5mm / 20mm x 20mm
  • Motor Mounting Holes: 16mm x 16mm / 19mm x 19mm
  • FC Mounting Holes: 30.5mm x 30.5mm
  • Dimension: 214mm x 168mm x 42mm
  • Camera Installation Space: 19-20mm
  • Suitable Propeller Size: 5″propeller
  • Motor to Motor Distance: 225mm
  • Frame Configuration: Squashed-X
  • Bottom Plate: 2.5mm
  • Arm Plate: 5.0mm
  • Top Plate: 2.5mm
  • Weight: 130.0
  • Version: Pro
  • Color: Black

Includes

  • 1x GEPRC Mark5 GEP-MK5 Bottom Plate
  • 1x GEPRC Mark5 GEP-MK5 Mid Plate
  • 1x GEPRC Mark5 GEP-MK5 Top Plate
  • 4x GEPRC Mark5 GEP-MK5 5″ Arms
  • 2x Action Camera Mount Holder
  • 1x Antenna Fixed Tube
  • 1x 3d Printed Part Set
  • 2x Camera Plates
  • 1x Allen Key Set
  • 1x Hardware Kit
  • 1x Standoff Set
  • 2x Battery Pad
  • 3x LiPo Straps
  • 8x Dampers
  • 1x Wrench
Weight 0.4 kg
Dimensions 18 × 20 × 6 cm
