DJI Goggles N3 FPV GOGGLES – Next-Generation

Compatibility Chart

DJI Goggles N3 HD FPV Experience for Digital Drone Pilots

The DJI Goggles N3 redefine what it means to experience First Person View. Designed for pilots who demand ultra-low latency, sharp image quality, and a wide field of view, the Goggles N3 integrate perfectly with DJI’s O4 and digital FPV systems, delivering crystal-clear 1080p video transmission in real time. Whether you’re racing through tight gaps or capturing cinematic footage, the Goggles N3 offer immersive visuals backed by rock-solid hardware.

🎯 Key Features of DJI Goggles N3 – Built for the Modern Pilot

🔥 True HD Video Transmission at 1080p/100fps

With support for 1080p at up to 100fps, the Goggles N3 enable real-time responsiveness and precision flight control, even during high-speed maneuvers. This gives pilots a serious edge when racing or flying through technical freestyle routes.

• Max Resolution: 1080p

• Max Frame Rate: 100fps

• Latency: As low as 28ms with O4 system

• Transmission Frequency: 2.4GHz and 5.8GHz dual-band switching

📡 DJI O4 and Digital System Compatibility

The Goggles N3 are optimized for the latest DJI O4 digital transmission system, providing increased range, stronger signal penetration, and reliable feeds even in high-interference environments. Backward compatibility with O3 Air Unit ensures flexibility for pilots using older air units.

DJI Goggles N3 Compatibility:

• DJI O4 Air Unit

• DJI O3 Air Unit

• DJI Avata 2 / DJI FPV Drone

• Supports ELRS/UART RX Pass-through for digital builds

🖥️ Advanced Dual Micro-OLED Display Technology

Each eye features a high-resolution micro-OLED screen that delivers vivid colors, deep contrast, and lifelike video quality. Unlike standard LCD panels, OLED ensures zero light leakage and better performance in dark conditions—ideal for navigating tunnels or night flights.

• Display Type: Micro OLED

• Resolution per Eye: 1920 × 1080

• Field of View: 50°

• Interpupillary Distance: Adjustable (56–72mm)

🎧 Built-In Audio and DVR Functionality

Capture every second of your flight with the built-in DVR (Digital Video Recording) system, allowing real-time footage storage on a microSD card. The integrated audio-out port lets you connect external headphones for an even more immersive experience while flying or reviewing footage.

• DVR Format: MP4

• Max SD Card Support: 256GB

• Audio-Out: 3.5mm port

• Firmware Upgrade: Via USB-C

⚙️ Ergonomic Design for Extended Flight Sessions

The Goggles N3 are crafted for comfort during long flying sessions. The lightweight adjustable headband, cushioned facial foam, and balanced weight distribution reduce fatigue, making them perfect for marathon flights or professional shoots.

• Weight: Approx. 400g

• Ventilation: Active cooling system

• Power Input: USB-C PD (9V-12V supported)

• Strap: 3-point adjustable head strap

📦 What’s in the Box?

• 1x DJI Goggles N3

• 1x Antenna Set (O4 compatible)

• 1x Head Strap

• 1x USB-C Power Cable

• 1x Protective Carrying Case

• 1x Quick Start Guide

Read More About Lipo Batteries by clicking the link below:
https://oscarliang.com/fpv-drone-guide/

Checkout our Frames Collection by clicking the link below:
https://thefpvproject.com/product-category/frames/

1S = 1 cell  = 3.7V
2S = 2 cells = 7.4V
3S = 3 cells = 11.1V
4S = 4 cells = 14.8V
5S = 5 cells = 18.5V
6S = 6 cells = 22.2V

For example, we call a 14.8V battery a “4-cell” or “4S” battery.

LiPo battery is designed to operate within a safe voltage range, from 3V to 4.2V. Discharging below 3V could cause irreversible performance loss and even damage to the battery. Overcharging above 4.2V could be dangerous and eventually cause a fire.

However, it’s advisable to stop discharging when it reaches 3.5V for battery health reasons. For example for a 3S Lipo, the max voltage is 12.6V, and you should land when the voltage reaches 10.5V (at 3.5V per cell).
