Hummingbird V3.1 RaceSpec ELRS 16.5g BNF – Complete Buyer’s Guide & Review

Hummingbird V3.1 RaceSpec ELRS BNF – The Ultimate Tiny Whoop Drone for FPV Racers

The Hummingbird V3.1 RaceSpec ELRS BNF is a compact yet high-performance FPV drone engineered for serious racers and freestyle enthusiasts. Built with cutting-edge ExpressLRS technology, refined flight dynamics, and a highly durable design, it delivers a powerful racing experience that is unmatched in the micro drone category.

•Firmware: Betaflight 4.5 KAACK, with RPM Limit for spec racing.

” alt=”” aria-hidden=”true” />

Specification:

⚡ Overview – A New Standard for Whoop Performance

At The FPV Project, we understand what pilots demand: speed, precision, reliability, and control. The Hummingbird V3.1 RaceSpec is crafted to exceed expectations in each of these domains. It combines premium electronics, optimized weight distribution, and responsive tuning — resulting in the smoothest whoop flying experience possible.

Key Highlights

• Flight Controller: F4 1S 12A AIO with built-in ExpressLRS receiver

• Motors: 0802 22000KV RaceSpec brushless motors

• Propellers: 31mm 4-blade props for high thrust and stability

• Camera: BeeEye 2.1 FPV camera for sharp and vivid visuals

• VTX: Integrated 25/100/200mW video transmitter with SmartAudio

• Frame: Lightweight yet durable polycarbonate frame

• Weight: 22.9 grams (without battery)

• Battery Support: 1S LiHV (300mAh – 450mAh recommended)

🧠 Flight Performance – Precision Meets Agility

The Hummingbird V3.1 RaceSpec isn’t just about raw speed; it’s designed to handle tight corners, sudden flips, and hairpin turns with finesse. The upgraded 0802 RaceSpec motors offer insane RPM with minimal latency, making it ideal for competitive indoor and outdoor whoop racing.

Flight Control System

Powered by the BeeBrain BLV3.1 flight controller, this drone features:

• F4 processor for ultra-fast response time

• Integrated 12A ESC for clean power delivery

• Native ExpressLRS 2.4GHz system for sub-10ms link latency

• Gyro precision tuned for crisp acro performance

Together, these components ensure ultra-smooth flight handling, even during aggressive acrobatics.

🧩 Build Quality & Design – Lightweight, Strong, and Smart

The Hummingbird V3.1 uses a polycarbonate canopy and frame, engineered for both minimal weight and high impact resistance. The smart component placement keeps the center of gravity perfectly balanced, allowing seamless transitions in every maneuver.

Durability Features

• Reinforced motor mounts to absorb crash impact

• Flexible canopy with camera protection

• Optimized airflow for efficient cooling

• Easily serviceable design for quick swaps and upgrades

🚀 ExpressLRS 2.4GHz – Redefining Low Latency Control

ExpressLRS (ELRS) is the most advanced open-source RC link protocol in FPV today. The Hummingbird V3.1 RaceSpec integrates an ELRS receiver directly into the flight controller, minimizing weight and maximizing signal reliability.

Benefits of ELRS Integration

• Sub-10ms latency for near-instant response

• Over 1km range (with suitable antennas)

• Dynamic power scaling up to 100mW

• Built-in failsafe and telemetry support

This means smoother flights, better penetration through walls and obstacles, and unmatched control consistency.

🎥 FPV System – Crystal Clear Visuals

Equipped with the BeeEye 2.1 FPV camera, the Hummingbird V3.1 offers low-latency analog video transmission through its 25/100/200mW adjustable VTX. Whether you’re racing indoors or exploring outdoor environments, the image clarity remains sharp with excellent color reproduction.

Camera Specs

⚙️ Recommended Setup

🏁 Flight Modes & Tuning

The Hummingbird V3.1 comes pre-flashed with Betaflight, optimized for racing and freestyle agility. It supports all major flight modes:

• Acro Mode for advanced pilots

• Angle Mode for smooth indoor control

• Horizon Mode for beginners transitioning to acro

Custom tuning is easy through the USB-C Betaflight configurator, allowing users to adjust PID, rates, filters, and throttle curves for personal preference.

Understanding the Causes of LiPo Battery Failure in FPV Drones

LiPo (Lithium Polymer) batteries are the lifeblood of FPV drones, powering everything from the motors to the electronics that enable your quadcopter to soar through the skies. While these batteries are essential for high-performance flying, they are also delicate and prone to failure or premature death if not handled correctly. In this article, we’ll explore the various causes of LiPo battery failure, helping you to extend the lifespan of your batteries and ensure consistent performance during your flights.

1. Overcharging and Overvoltage

One of the most common causes of LiPo battery failure is overcharging. Charging a LiPo battery beyond its maximum voltage—typically 4.2V per cell—can cause significant damage. Overcharging can lead to the swelling of the battery cells, increased internal resistance, and, in extreme cases, thermal runaway, which can result in fire or explosion.

• Prevention: Always use a quality balance charger with built-in safety features to prevent overcharging. Ensure that you never exceed the recommended charge voltage for your specific LiPo battery.

2. Overdischarging

Overdischarging occurs when a LiPo battery is drained below its safe minimum voltage, typically around 3.0V per cell. Discharging a battery too low can cause irreversible chemical changes within the cells, leading to a loss of capacity, increased internal resistance, and eventual failure.

• Prevention: Use a low-voltage alarm or set your drone’s flight controller to warn you when the voltage drops below a safe threshold. It’s also advisable to land your drone as soon as the voltage drops to around 3.5V per cell under load, giving you a buffer to avoid overdischarge.

3. Physical Damage

LiPo batteries are particularly vulnerable to physical damage, which can occur due to crashes, punctures, or rough handling. Any damage to the battery casing can lead to exposure of the internal cells, which may result in swelling, leakage, or short circuits.

• Prevention: Always inspect your batteries after a crash or rough landing. If you notice any dents, swelling, or other signs of damage, it’s best to safely dispose of the battery rather than risk using it. Protect your batteries with soft cases or padding during transport and in your drone.

4. High Current Draw

FPV drones, especially those built for racing or freestyle flying, often draw high currents from their batteries. While LiPo batteries are designed to handle high current loads, drawing excessive current for extended periods can cause overheating, swelling, and a decrease in battery lifespan.

• Prevention: Ensure that your battery’s C-rating (the measure of how much current the battery can safely deliver) matches the demands of your drone’s setup. Avoid pushing your batteries to their limits during every flight, and consider using batteries with a higher C-rating for demanding flying styles.

5. Improper Storage

Improper storage is a major factor in the premature aging of LiPo batteries. Storing LiPo batteries fully charged or fully discharged for extended periods can cause capacity loss and increase the risk of swelling.

• Prevention: Store your LiPo batteries at a storage voltage of around 3.7V to 3.85V per cell. Use a balance charger’s storage mode to set your batteries to the correct voltage before storing them in a cool, dry place. Avoid storing batteries in hot environments, such as inside a car or near direct sunlight.

6. Poor Charging Practices

Charging LiPo batteries improperly can lead to a range of issues, from reduced capacity to complete failure. Using incorrect settings on your charger, charging at too high or too low a current, or using a damaged charger can all contribute to battery failure.

• Prevention: Always double-check your charger settings before plugging in your batteries. Charge your batteries at a moderate rate (typically 1C, where C is the battery’s capacity) unless you’re confident that a faster charge won’t harm the battery. Regularly inspect your charger for wear and tear, and replace any damaged components.

7. Environmental Factors

Environmental conditions such as extreme temperatures, humidity, and exposure to water can also lead to LiPo battery failure. High temperatures can cause the battery cells to swell, while cold temperatures can reduce capacity and increase internal resistance. Exposure to moisture can lead to short circuits and corrosion.

• Prevention: Fly and store your batteries within their recommended temperature ranges. Keep them dry, and avoid flying in rainy or excessively humid conditions. If you suspect that a battery has been exposed to moisture, allow it to dry thoroughly before use, but be cautious as the internal damage may have already occurred.

8. Age and Usage Cycles

Even with the best care, LiPo batteries have a finite lifespan. Over time and through repeated charge/discharge cycles, the chemical composition of the cells degrades, leading to reduced capacity, increased internal resistance, and eventually, failure.

• Prevention: Monitor the performance of your batteries regularly. If you notice a significant drop in flight time or increased swelling, it may be time to retire the battery. Keeping a log of your battery usage can help you track the number of cycles and predict when a battery is nearing the end of its useful life.

Read More About Lipo Batteries by clicking the link below:
https://oscarliang.com/fpv-drone-guide/

Checkout our Frames Collection by clicking the link below:
https://thefpvproject.com/product-category/frames/

1S = 1 cell  = 3.7V
2S = 2 cells = 7.4V
3S = 3 cells = 11.1V
4S = 4 cells = 14.8V
5S = 5 cells = 18.5V
6S = 6 cells = 22.2V

For example, we call a 14.8V battery a “4-cell” or “4S” battery.

LiPo battery is designed to operate within a safe voltage range, from 3V to 4.2V. Discharging below 3V could cause irreversible performance loss and even damage to the battery. Overcharging above 4.2V could be dangerous and eventually cause a fire.

However, it’s advisable to stop discharging when it reaches 3.5V for battery health reasons. For example for a 3S Lipo, the max voltage is 12.6V, and you should land when the voltage reaches 10.5V (at 3.5V per cell).
