Axis flying C246 2406 For 6″ Of Freestyle / Sbang / Cinematic Shooting Drone (Set of 4 Motors)

7,999.00

Overview:

  • The C series motor features the perfect balance required for your cinematic flights: smoothness, reactivity, and high torque.

Out of stock

SKU: SKU7797546 Categories: ,
Spread the love

Axis flying C246 2406 For 6″ Of Freestyle / Sbang / Cinematic Shooting Drone (Set of 4 Motors) Specifications & Description:

  • With FPV trending in cinematic and commercial filming, we – Axis flying – are very proud to present you our new C cinematic motor series.
  • The C series motor has been developed for Cinematic FPV pilots who fly to create and have high-quality requirements.
  • Cinematic pilots often only have one chance to capture their best shot so they work hard to fine-tune their flying abilities and master: control, anticipation, and precision. Today, we bring a new cinematic motor to help you enhance your cinematic flying skills.
  • The C series motor features the perfect balance required for your cinematic flights: smoothness, reactivity and high torque for a delicate control feel and high efficiency to maximize your flight time.

Axis Flying Foreword:

  • The C246 motor features the perfect balance required for your cinematic flights: smoothness, reactivity and high torque for a delicate control feel and high efficiency to maximize your flight time.
  • We’ve designed the C series motors with the contribution of the cinematic FPV experts: Antoine DG (@Escape_fpv) and Fry (@Fry_fpv). Their cinematic knowledge and ideas led us today to introduce you to these top-grade cinematic motors.
  • We want to thank David and Jasonfpv who helped us with their repeated testing and feedback to accelerate the presence of Axis flying in the growing cinematic FPV market.
  • Bearing Shield Technology
  • An IP53 rating dustproof and waterproof bearing placement design.
  • BST protects from environmental elements and prolongs the smoothness and lifespan of the bearing.
  • Increased thrust efficiency and say goodbye to crush motor bearings

Motor Specs:



  • 1650KV is for 6inch props @6S of cinematic shooting
  • 1850KV is for 5inch props @6S of speed cinematic shooting (such as motorcycle race)
  • 2050KV is for 5inch props @6S of sbang freestyle
  • Configuration: 12N14P / N52H arc magnet
  • Motor stator size: 2406
  • Motor mounting hole size: 4*M3 (Φ16mm)
  • Motor cables: AWG 20#, 150MM
  • Motor dimensions (Dia *Len): Φ29.3*31.8MM  / M5 shaft
  • Motor weight (including 150MM cables): 31g
  • The motor is potent that can get over 2KG and the most current is about 45A

Axis Flying Package:

  • 4* C246 motor 1650KV
  • 4* M3*8 screws for motor
  • 1* M3*4 screw for the lock shaft
  • 1* M5 Flanged Nylon Insert lock
  • 1* O-ring
  • 1* Washer

Read More About Lipo Batteries by clicking the link below:
https://oscarliang.com/fpv-drone-guide/

Checkout our Frames Collection by clicking the link below:
https://thefpvproject.com/product-category/frames/

1S = 1 cell  = 3.7V
2S = 2 cells = 7.4V
3S = 3 cells = 11.1V
4S = 4 cells = 14.8V
5S = 5 cells = 18.5V
6S = 6 cells = 22.2V

For example, we call a 14.8V battery a “4-cell” or “4S” battery.

LiPo battery is designed to operate within a safe voltage range, from 3V to 4.2V. Discharging below 3V could cause irreversible performance loss and even damage to the battery. Overcharging above 4.2V could be dangerous and eventually cause a fire.

However, it’s advisable to stop discharging when it reaches 3.5V for battery health reasons. For example for a 3S Lipo, the max voltage is 12.6V, and you should land when the voltage reaches 10.5V (at 3.5V per cell).

Weight 0.3 kg
Dimensions 18 × 10 × 10 cm
KV Rating

1950 KV, 2550 KV
